Product Details:
|
| Name: | 40T Razor Barbed Wire Razor Barbed Iron Wire Machine | Key Selling Points: | Competitive Price |
|---|---|---|---|
| Pressure: | 25Ton Or 40Ton | Voltage: | 380V,50Hz Or According To Client's Voltage |
| Producing Speed: | 220-280m/h | Dimension(mm): | 1100*1000*2000 |
| Type: | Fully Automatic | Warranty: | 2 Years |
| Product Name: | Razor Wire Mesh Machine | Material: | Galvanized Steel Sheet And Wire |
| Usage: | Automatic Control Operation | Thickness: | 0.5±0.05mm |
| High Light: | 380V Razor Blade Wire Making Machine,ISO Razor Blade Wire Making Machine,Fireproof Razor Blade Manufacturing Machine |
||
40T Razor Barbed Wire Razor Barbed Iron Wire Machine
Razor barbed wire machine produce razor barbed wire, The razor wire machine is composed of the main machine producing strip plates and the coiling machine that coils the wire into the strip plate. Razor barbed wire machine is light, easy to operate, high efficient. Using this type of razor barbed wire machine can save you twenty percent of raw materials in production.
The automatic razor barbed wire punching machines are designed and manufactured by our own factory, The main characteristics of our products are high quality, best price, good performance and easy operation. We can also adjust our machines per customers'request.
| MODEL | 25T | 40T | 63T | COILING MACHINE |
| VOLTAGE | 3phase 380V/220V/440V/415V, 50HZ or 60HZ | |||
| POWER | 4KW | 5.5KW | 7.5KW | 1.5KW |
| PRODUCING SPEED | 70TIMES/MIN | 75TIMES/MIN | 120TIMES/MIN | 3-4TON/8H |
| PRESSURE | 25TON | 40TON | 63TON | -- |
| MATERIAL THICKNESS AND WIRE DIAMETER | 0.5±0.05(mm), according to customers' requirement | 2.5MM | ||
| MATERIAL OF SHEET | GI and stainless steel | GI and stainless steel | GI and stainless steel | ----- |
BLADE TYPES:
| STYLE | BARBE LENGTH | BARB WIDTH | BARB SPACE | STEEL TAPE SHAPE |
| BTO-10 | 10±1 mm | 13±1mm | 26±1mm |  |
| BTO-12-1 | 12±1mm | 13±1mm | 26±1mm | |
| BTO-12-2 | 12±1mm | 15±1mm | 26±1mm | |
| BTO-18 | 18±1mm | 15±1mm | 33±1mm | |
| BT0-22 | 22±1mm | 15±1mm | 48±1mm | |
| BTO-28 | 28±1mm | 15±1mm | 49±1mm | |
| BTO-30 | 30±1mm | 18±1mm | 49±1mm | |
| BTO-60 | 60±1mm | 32±1mm | 96±1mm | |
| BTO-65 | 65±1mm | 21±1mm | 100±1mm | |
It mainly consists of decoiler, punching machine, recoiler, razor wire covering machine, control cabinet etc.
This type has advantages of easy operation, easy maintain, high speed and low energy consumption.
