Product Details:
|
| Name: | Iron Wire Gabion Mesh Gabion Hexagonal Wire Mesh Basket For River | Mesh Width: | Can Be Customized |
|---|---|---|---|
| Certification: | CE, ISO9001 Standard | Hole Shape: | Hexagonal |
| Wire Guage: | 0.3mm-8.0mm | Wire Gauge: | 0.6mm To 4.4mm |
| Application: | Gabions | Material: | Galvanized Iron Wire,Plastic Coated Iron Wire |
| Surface Treatment: | Hot-dipped Galvanized /Electro Galvanized /pvc Coated,hot Dipped Galvanized | Feature: | Anti-corrosion,Eco Friendly |
| High Light: | Iron Hexagonal Chicken Mesh,Rustproof Hexagonal Chicken Mesh,Eco Friendly PVC Hexagonal Mesh |
||
Iron Wire Gabion Mesh Gabion Hexagonal Wire Mesh Basket For River
Stone cage net introduction:
1. Gabion is made of steel mesh with the type 80*100mm,60*80mm,70*90mm or 100*120mm ....mesh
2. The diameter of the wire mesh can be produced according to customer's requirment.
3. The gabion element is in the shape of block or regular cube size. These special wire bins are made of robust wire, filled with the vibrations at the quarry and transport are accompanied by the lifting straps.
4. Wires of gabion basket can be classified into mesh wire, selvedge wire and tie wire. The selvedge wire is thicker than the other two wires.
Specification og gabion wire mesh:
| mesh size (mm) |
Wire Diameter (metal type mm) | Wire Diameter (PVC Coate type )/ Inner/Outside(mm) |
| 60X80 | φ2.0-3.2 | φ2.0/3.0-2.5/3.5 |
| 80X100 | φ2.0-3.2 | φ2.0/3.0-2.8/3.8 |
| 80X120 | φ2.0-3.2 | φ2.0/3.0-2.8/3.8 |
| 100X120 | φ2.0-3.4 | φ2.0/3.0-2.8/3.8 |
| 100X150 | φ2.0-3.4 | φ2.0/3.0-2.8/3.8 |
| 120X150 | φ2.0-4.0 | φ2.0/3.0-3.0/4.0 |
Eclogical stone cage has four advantages:
One is the construction is simple,Ecological stone cage technology only stone into the cage can be sealed,do not need special technology,also do not need water and electricity,
Second,the cost is low.
Third , The landscape and protection effect is good.Ecological stone cage process using the combination of engineering measures and plant measures,can effectively prevent soil erosion,landscape effect is fast,The landscape effect is more natural ,more rich.
Four is long service life,ecological stone cage process life for decades,and generally do not have to repair.
FAQ:
Q:Are you a real factory?
A:yes,Hebei Hengtuo machinery Equipment Co.,LTD not only produces all kinds of stone cage machine,and the production of stone cage net,from the sources for customers to control the quality.
Q:Does your factory has export rights?
A:YES.We have more than 30 year's export experience.Your customer clearance is no problem.
Q:May I visit your factory?
A:YES,You are very welcome to visit our factory and give us your valuable advice,
